General Information |
LG2C2L/F |
LG4C2L/F |
LG6C1L/F |
LG2C5L/F |
LG1C5L/F |
Container
|
Theoretical output Max container volume Max neck diameter Max container diameter Max container height Number of cavity
|
2500 pcs/hr 1.5L 45mm 100mm 340mm 2 Cavity |
4000pcs/hr 1.5L 45mm 100mm 340mm 4Cavity |
6000pcs/hr 0.6L 45mm 67mm 270mm 6Cavity |
1200pcs/hr 5L 50mm 175mm 350mm 2Cavity |
750pcs/hr 5L 50mm 175mm 350mm 1Cavity |
Electrical System
|
Total power Use power |
25kw 15kw |
35kw 21kw |
45kw 27kw |
40kw 25kw |
25kw 15kw |
Air System
|
Working pressure Low pressure consuming Blowing pressure High pressure consuming |
1.0 Map 1400L/min ≤3.5Mpa 1200L/min |
1.0 Map 1600L/min ≤3.5Mpa 2400L/min |
1.0 Map 1600L/min ≤3.5Mpa 3600L/min |
1.0 Map 1600L/min ≤3.5Mpa 2400L/min |
1.0 Map 1400L/min ≤3.5Mpa 1200L/min |
Chiller Water
|
Operating pressure Temperature Flow rate |
0.3-0.5Mpa 10-12℃ 30L/min |
0.3-0.5Mpa 10-12℃ 45L/min |
0.3-0.5Mpa 10-12℃ 75L/min |
0.3-0.5Mpa 10-12℃ 45L/min |
0.3-0.5Mpa 10-12℃ 30L/min |
Machine
|
Machine dimension Machine weight Feeding Machine dimension Feeding Machine weight |
1.9×1.6×2.0m 1300kg 2.0×1.0×2.0m 200kgs |
2.5×2.0×2.0m 2200kg 2.0×1.0×2.0m 220kgs |
4.2×2.0×2.0m 4200kg 2.0×1.2×2.0m /2.1×0.9×2.0m 200kgs |
2.5×2.0×2.0m 1900kg 2.0×1.0×2.0m 200kgs |
2.0×1.4×2.0m 1600kg 2.0×1.0×2.0m 200kgs |
